There are some criteria for a successful heat exchanger design.  These principles are given below The process requirements which are accomplishing the thermal change on the streams within the allowable pressure drops, and retaining the capability to do this in the presence of fouling until the next scheduled maintenance period must be...

The thermal design of heat exchangers is directed to calculate an adequate surface area to handle the thermal duty for the given specifications whereas the hydraulic analysis determines the pressure drop of the fluids flowing in the system, and consequently the pumping power or fan work input necessary to maintain the flow.  The most common...

COMPONENTS OF SHELL AND TUBE HEAT EXCHANGER 1.Shell 2. Fin Tube 3. Stationary Head 4. Lap Jointed Flange 5. Channel Cover 6. Stationary Tube sheet 7. Floating Tube sheet 8. Nozzle 9. Front Backing Device 10. Rear Backing Device 11. Saddle Support 12. Gasket

In a shell and tube heat exchanger two fluids circulate in a different temperature conditions exchange heat through the walls of the tubes without direct contact between the fluids. The fluid flowing inside the heat transfer tubes that belongs to the tube bundle they finds the tube side of a shell and tube heat exchanger. […]

Gravitational separation of liquid and vapor also plays an important part in the functioning of condensers, of which many designs exist, their nature determined largely by the ratio of the condensed to the uncondensed components in the fluid stream being cooled. Even when the cooled stream is nominally wholly condensable, as is true of stream...
