Use of Cooling Tower

 The primary function of a coolingtower is to remove waste heat from a water-based system and reject it
to the atmosphere. This is achieved primarily through the principle of
evaporative cooling.

Here is a detailed breakdown of the key functions of a cooling tower:

1. Primary Function: Heat Rejection

This is the core reason cooling towers exist. They are designed to
efficiently extract waste heat from processes or building cooling systems and
dissipate it into the air. This prevents machinery from overheating and allows
processes to run continuously.2. Water Cooling for ReuseCooling towers don’t just get rid of heat; they cool down the water that
absorbed the heat so it can be used again. This creates a closed-loop or recirculating system.
The function is to:

This cycle repeats continuously, making the system highly efficient and
sustainable.

3. Conservation of Water and Energy

While cooling towers use evaporation (which consumes water), their
recirculating design is a major function for conservation:

• Water
  Conservation: They
  save massive amounts of water compared to a “once-through”
  system, where water is used once and then discharged. A recirculating
  system might make up only 1-2% of the water volume lost to evaporation,
  drastically reducing the need for fresh water.


• Energy
  Conservation: Providing
  a continuous supply of cooled water allows systems like chillers and
  condensers to operate much more efficiently, saving significant energy
  compared to using warm, fresh water.

4. Maintaining System Efficiency

The efficiency of many industrial processes and HVAC systems is directly
tied to the temperature of the cooling water. The function of the cooling tower
is to provide a reliable supply of water at the optimal temperature to
ensure these systems run at peak performance. Warmer cooling water makes air
conditioners work harder and power plants less efficient.

5. Environmental Protection

By recirculating water, cooling towers minimize thermal
pollution. Discharging large volumes of hot water directly into rivers or
lakes can harm aquatic ecosystems. Cooling towers release the heat into the
atmosphere instead, which is a much more benign form of heat rejection.

How These Functions Are Achieved: The Process

To fulfill these functions, a cooling tower performs a specific process:

1. Heat Transfer: Hot water from the industrial process or condenser is pumped
   to the top of the tower.


2. Distribution: This water is distributed across the “fill” (a
   large internal surface area). This maximizes water-to-air contact.


3. Evaporation: Air is drawn through the falling water by large fans. A small
   portion of the water evaporates.




• This
  is the key: The
  process of evaporation requires energy (the “latent heat of
  vaporization”). This energy is taken from the remaining water,
  thereby cooling it significantly.




4. Collection
   & Recirculation: The
   now-cooled water collects in a basin at the bottom and is pumped back to
   the plant to absorb more heat.


5. Heat
   Dissipation: The
   warm, moist air created by evaporation is exhausted to the atmosphere,
   carrying the waste heat with it.
